Vélo BOLD Linkin 150 Ultimate
Modèle : 291169
Caractéristiques clés
- Cadre HMX LINKIN en carbone
- FOX 36 Float Factory, 150mm
- FOX Nude 5T Factory EVOL
- SRAM XX1 Eagle AXS / Sans fil
- Shimano XTR M9120 à disque 4 pistons
- Syncros Revelstoke 1.0S-30 CL
- Syncros Hixon iC Carbon
1. Taille
Spécifications
-
Le LINKIN 150 est ce qui s’approche le plus de notre idée du VTT ultime. Pour les longues journées en hors-piste, ou simplement pour parcourir vos pistes locales, cette plateforme de 150 mm vous permettra de profiter au maximum de chaque trail. Notre design de suspension intégrée IST-VP maintient un centre de gravité bas entre vos pieds, afin de garantir une excellente adhérence du vélo au sol et une expérience de conduite agréable. Un astucieux kit « SAVE-THE-DAY » intégré vous fournira tous les outils dont vous aurez besoin en cas de pépin dans les bois. Existe-t-il l’équivalent du couteau suisse en VTT ? Si c’est le cas, c’est probablement le LINKIN 150.
Remarque : les caractéristiques du vélo sont susceptibles d’être modifiées sans préavis. -
Cadre
Bold Linkin 150 / Carbon HMX
Integrated Suspension Technology / IST VP
Vario Tech, Head angle and BB height / Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline -
Fourche
FOX 36 Float Factory Grip 2 Air / Kashima
HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle
44mm offset / tapered steerer
150mm travel -
Amortisseur arrière
FOX NUDE 5T Factory EVOL Trunnion
Custom travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Kashima / Reb. Adj.
T185X55mm / Travel 150-100-Lockout -
Levier de contrôle
TracLoc Technology
Rear Suspension & Dropper Remote
3 Rear Suspension modes
-
Dérailleur arrière
SRAM XX1 Eagle AXS / 12 Speed
Wireless Electronic Shift System -
Manettes de dérailleur
SRAM Eagle AXS Rocker Controller -
Pédalier
SRAM XX1 Eagle
Carbon crankarm
DUB / 55mm CL / 32T -
Guide-chaîne
Bold custom -
Boitier de pédalier
SRAM DUB PF 92 MTB Wide / shell 41x92mm -
Chaîne
SRAM CN XX1 Eagle -
Cassette
SRAM XX1 XG1299 / 10-52 T -
Freins
Shimano XTR M9120 4 Piston Disc -
Disque de frein
Shimano RT-MT900 CL / 203/F and 180/R -
Cintre
Syncros Hixon iC Carbon
Size S & M 15mm rise / Size L & XL 25mm rise
back sweep 8° / 780mm
Syncros Endurance lock-on grips -
Tige de selle
Syncros Duncan Dropper Post 1.5 34.9mm
Size S 170mm / Size M, L & XL 200mm -
Selle
Syncros Tofino Regular 1.0
Carbon rails -
Jeu de direction
Syncros - Acros Angle adjust & Cable Routing HS System
Stainless / +-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB -
Paire de roues
Syncros Revelstoke 1.0S-30 CL
F: 15x110mm / R: 12x148mm
30mm Tubeless ready Carbon rim 28H
DT Swiss 240 Ratchet EXP 36 / XD Driver
SRAM TyreWiz / Syncros Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools -
Pneu avant
Maxxis Minion DHF / 2.5" / 60TPI Foldable
Tubeless Ready / EXO -
Pneu arrière
Maxxis Minion DHF / 2.5" / 60TPI Foldable
Tubeless Ready / EXO -
Extras
Save the Day Kit
SRAM AXS Powerpack
SRAM TyreWiz
Syncros Fork Fender -
Accessoires vélo
Syncros Eco Sealant -
Poids en Kg (App.)
13Kg / 13.4kg
Utilisation
No Radar Chart Available Currently
Technologies
Athlète
PRIX ET MEDIA
Documents
Nos produits en action
Inspiration




Swiss brand Bold launched its first bike back in 2015 with a frame that was as clean as a glacial stream and a hidden shock that was better protected than a Geneva bank vault. With a single showroom in Beil, it remained an exclusive proposition, but in May 2019 Scott Sports bought a majority stake in the boutique brand, which allowed it to use the patented Internal Suspension Technology. Then, a year later, Scott launched a new Spark XC bike with, you guessed it, a hidden shock.

The bike we tested is a special build so we will be focussing our review on the frame itself only. The Bold Linkin is available as a frameset and a complete bike. The complete bikes come in a total of 4 different configurations. A ‘Pro’ and an ‘Ultimate’ spec are available in both 135mm and 150mm travel options.

BOLD CYCLES has just released its brand new bike, the LINKIN, and if its internally mounted shock wasn't crazy enough, it gets a super progressive geometry and the ability to switch from 135mm of travel up to 150mm with the change of a link. That's not all as it comes with a tonne of on-bike storage and a flip chip. Here's everything you need to know.

The BOLD LINKIN is offered with either 135 or 150 mm of travel, which can then be changed by the inner link. Four versions will be available, which differ in frame travel set-up and build specifications. Integration and handling are the key features on this innovative and technology driven, premium trail bike. The LINKIN will be available in 39 international markets.

The new Bold Linkin is a trail bike offering either 135 or 150mm travel, adjustable through the hidden shock, and takes inspiration from the latest Scott Spark. Most noticeable is the integration of the shock into the frame, sitting just above the bottom bracket and anchoring to the inside of the down tube, along with in-built storage for emergency tools (or the ‘save the day kit’, as Bold calls it).

Bold Cycles’ uniquely integrated, hidden-shock Linkin trail bike is back, with an all-new virtual pivot point suspension layout with updated progressive geometry and the ability to adapt rear wheel travel to your style of riding. Plus, its new horizontal shock layout inside the carbon frame lowers the bike’s center of mass once again, making the rear shock seem to disappear even more, yet easier to access at the same time.

As you might expect, Bold is continuing to use the internal shock design, however there are some big differences to its application on the new bike. Rather than standing vertically in the seat tube, the shock now lies horizontally above the bottom bracket. This gives Bold a low center of gravity that other brands could only dream of achieving and, it claims, also boosts the stiffness of the overall construction. As before, the shock is protected from the elements but is now accessed from a removable panel in the bottom of the downtube, rather than below the bottom bracket as before. A magnet-equipped travel indicator on the outside means you don't have to break open the bike to check the sag or know if you're bottoming out or not. Re-orienting the shock also means the seat tube is clear of any obstructions and a 200mm dropper post can be fitted.
